Addicore | SKU:
AD166
SW-18015P Vibration Sensor Switch (High Sensitivity)
$0.35
Unit price /
Unavailable
Shipping calculated at checkout.
SW-18015P Vibration Sensor Switch (High Sensitivity) is backordered and will ship as soon as it is back in stock.
Delivery
Delivery
Ships Same Day if Ordered Before Noon Pacific Time
SW-18015P Vibration Sensor Switch (High Sensitivity)
$0.35
Unit price /
Unavailable
Product Contents:
- 1 piece - SW-18015P Sealed High Sensitivity Vibration Sensor Switch
Specifications:
- Max voltage: 12V
- Max current: 50mA
- Conductive time: ~2ms
- Closed resistance <10 ohm
- Open resistance: >10M ohm
- Operating temperature range: -40 to 80 C
- Pull force of terminal: 500gf for 1 min
- Operating lifespan: up to 200,000 cycles
- Dimensions (excluding pin): 4.77mm (0.19in) diameter x 11.18mm (0.44in) length
- Dimensions (including pin): 21.5mm (0.85") length
- Weight: 0.22g (.008oz)
